Productinformatie:

Profile and pipe grinder / Belt sander This Cowley combination machine is a multifunctional grinding machine that is suitable for grinding the front of pipes and ends of profiles, surface grinding and cylindrical grinding. Tube grinding is done at the front of the machine, surface grinding at the top and circular grinding at the back. The sharpening angle is variably adjustable from 30 – 90° including depth stop. The strong electric motor works with two speeds. Ideal for grinding steel, stainless steel and non-ferrous metals. Rollers and grinding belts are easy to replace. Machine can be connected to a dust extraction. The grinding machine is supplied with a sanding belt 100 x 2000 mm (K36). The combi machine is supplied as standard with 1 sanding belt and the following grinding rollers: Ø 18 mm - ¾ Ø 23 mm - 1'' Ø 30 mm - 1'' ¼ Ø 38 mm - 1'' ½ Ø 48 mm - 2' ' Ø 63 mm - 2'' ½ Ø 74 mm - 3'' Features:

• angle adjustment from 30 to 90°
• separate emergency stop and separate start/stop button
• Incl. 7 grinding rollers
• 2 speeds
• can be connected to a dust extraction
• sanding belts and grinding rollers are easy to replace

Technical specifications:

• voltage = 400V / 50Hz
• motor power = 2.5 / 3.3kW
• motor speed = 1400 / 2800rpm
• belt speed = 23.5 / 47m/s
• sandable diameter = 20 - 76mm
• adjustable angle = 30 - 90°
• tire dimensions = 100 x 2000mm
